Effects of pH and CO2 on Microalgae


While microalgae are some of the most promising alternative energy sources, microalgal biodiesel production is not yet competitive with petroleum production costs. In this study, the researchers focused on how pH and CO2 affected microalgae growth. pH level is one of the most important factors in algal cultivation, as it determines the availability of CO2 and algal metabolism. The production and transportation of CO2 can also be a large cost factor.

Set Up:

The researchers used the microalgae Chlorella sorokiniana DOE1412 to evaluate cell growth and lipids at different pH. An optimal culturing pH range was determined by measuring the cell growth, lipid production, and CO2 addition. The algae were first tested in Erlenmeyer flasks, but then scaled up to a flat panel photobioreactor at higher pH levels. An Apogee MQ-200X quantum meter ensured the top of the flasks were illuminated at 200 μmol photons m-2    s-1.


This research found that biomass productivity increased in microalgae with decreasing pH levels. They found that a pH of 8 resulted in the lowest value of CO2 addition (2.01 g CO2 /g biomass). The fatty acid profiles and biodiesel properties were determined as a function of pH. Protein content in microalgal biomass increased with increasing pH, while the carbon to nitrogen ratio in cells decreased.


pH 6 seems most beneficial for growth and lipid accumulation. However, pH 8 was more cost-effective, even though the growth rate was lower. The amount of lipid was similar regardless of pH. This research shows that there must be a balance between biomass growth, lipid production and CO2 addition in microalgal production.

Read the full article here >

PDF version >

Green stylized green glass that looks like microalgae

Image 2. Photo by The Tampa Bay Estuary Program; Seagrass and microalgae


Application Summary

Old propane fuel cannisters

Image 1. Photo by Scott Evans; Old propane fuel cannisters

Apogee’s MQ-200X quantum meter helped demonstrate the need for balance between biomass growth, lipid production and CO2 addition in microalgal production.
Apogee Sensor Used
  • ‪Renhe Qiu
  • ‬‬‬‬‬‬‬Song Gao
  • ‬‬‬‬‬‬‬‪Paola A. Lopez
  • ‬‬‬‬‬‬‬‬‬‬‪Kimberly L. Ogden‬‬
Reference Article
