Humidity Probe Support

Specifications
Product Manuals
Spec Sheets
Technical Drawings
Software & Datalogger Programs



Humidity Probe Specifications
Specifications Icon
  EE08-SS
Input Voltage 7 to 30 V DC
Current Draw Less than 1.3 mA
Start-up Time 2 s
Housing Polycarbonate, IP65
Filter Stainless steel wire mesh, 30 micron pore size
Connector M12, IP67
Dimensions 83 mm length, 12 mm diameter
Mass with 5 m Cable 270 g
Operating Environment -40 to 60 C; 0 to 100 % relative humidity
Cable M12 connector (IP67 rating) to interface to sensor housing, 5 m of four conductor, shielded, twisted-pair wire (10 m and 20 m cables also available), white TPR jacket (high water resistance, high UV stability, flexibility in cold conditions), pigtail lead wires
Warranty 1 year against defects in materials and workmanship
  Temperature Measurement
Sensor PT1000 (Class A)
Measurement Range -40 to 60 C
Output Signal Range 0 to 2.5 V DC
Accuracy at 20 C ± 0.2 C
Long-term Stability Less than 0.1 C per year
Time Constant Less than 30 s
  Relative Humidity Measurement
Sensor Capacitance Chip
Measurement Range 0 to 100 %
Output Signal Range 0 to 2.5 V DC
Accuracy at 20 C ± 2 % RH from 0 to 90 %; ± 3 % RH from 90 to 100 %
Temperature Response Less than -0.05 % per C
Long-term Stability Less than1 % per year
Time Constant Less than 30 s



Humidity Probe Product Manuals
Product Manuals Icon

EE08-SS Manual >



Humidity Probe Specification Sheets
Specification Sheets Icon

EE08-SS Spec Sheet >



Humidity Probe Technical Drawings
Technical Drawings Icon

EE08-SS Tech Drawing >
